3) Cleaning of rubber parts Rubber parts are not allowed to be washed by mineral washing oil. Instead, they should be washed in alcohot; or alternatively. the dirts on the surface should be wiped off via a piece of clean cloth.4) Purge of oil pipeline Use steel wire to get through the oil circuit

9)Remove the dust sealing ring and the grease nipple from the spider.10) Clamp the spline fork in the vice, remove the boot, felt and grease nipple.4.2 Cleaning1) Cleaning Notes Cleaning is necessary given the accumulation of oil and dirt on the parts. Ways of cleaning suitable for the cleaning inc

On the March Purchasing Festival, Yunnnuo Automobile will offer customers the best price.The promotion activity in March starts on March 1st and ends on March 31st.If we receive the deposit in March, we have various gifts for customers.Yunnuo Automobile China have Toyota Coaster, Yutong buses, Sinot

Note: If the flange fork is provided with cover plates on both sides, beat out the lock washer of the bolt, unscrew the bolt and take off the clamping plate.(3)Remove the cup on one end in the axial direction of the spider with a press (or hammer) (take care not to disorder or loseneedle rollers in

This week, the fourth and fifth Toyota Coasters renovated for a Nigerian customer have been fully completed and successfully transported to the port. They are about to set sail for the African continent. This achievement not only marks the entry of the cooperation between the two parties into a new

6) Remove the joint between the transmission and the transmission shaft and remove the transmission shaft assembly from the vehicle.7) Before disassembling the transmission shaft, make aligning marks as shown in the figure.Aligning mark8) Remove the flange fork.(1) Remove the two retainers on both s

3.3 When the vehicle is idling, be cautious of the transmission shaft for any abnormal noise, the working condition of the trans-mission shaft should be checked frequently.3.4 Check the oil sea l effect of the transmission shaft. Generally, it is identified as effective oil seal if there is uniform

1、 FunctionThe function of the transmission sh aft is to transfer the power generated by the engine to the rear axle through the gear box to drive the wheels to rotate so that the vehicle can move forward or backward. The transmission shaft is connected to the gear box (or retarder) and rear as le

Type of gear oil API GL-4 and aboveViscosity grade can be selected in accordance with the stable atmosphere temperature in the local area.85W/140 used in the area with atmosphere temperature between - 15℃ and 49℃80W/90 used in the area with atmosphere temperature between - 25℃ and 49℃80W/140 used in

Recommended Oils, Liquids and Filling Amount1、 Diesel oilUsers can select different grades of diesel oil in accordance with the stable atmosphere temperature in the local area.0# light diesel oil used in the area with atmosphere temperature above 4℃10# light diesel oil used in the area with atmosph
